YJGQ Series Hydraulic Rail Clip Device

YJGQ Series Hydraulic Rail Clip Device

1.Introduction YJGQ series hydraulic rail clip device Original:He Nan, China Certification: ISO9001, ISO14001, OHSAS18001, TX, EX, MA etc Packing: export standard Operating Condition" Ambient temperature: -0°C~+40°C ; Hydraulic station power: AC380v, 50HZ Hydraulic station control power: AC......

Send Inquiry

1.Introduction

YJGQ series hydraulic rail clip device

Original:He Nan, China

Certification: ISO9001, ISO14001, OHSAS18001, TX, EX, MA etc

Packing: export standard

Operating Condition" Ambient temperature: -0°C~+40°C ;

Hydraulic station power: AC380v, 50HZ

Hydraulic station control power: AC 220V, 50HZ

Limit switch power: AC 125V-250V

Working methods: intermittent, short-term effect, a lower frequency

Special requirements can be discussed in order.


2.Application:

YJGQ hydraulic rail clip is mainly used for kinds of bridge rail, rail gantry container crane and other mechanical work or work under the state was to resist wind and other external impact.


3.Main Feature:

1. Normal close design, the spring force clamping, hydraulic cylinder drive release

2. Anti-corrosion design.

3. It make protection for traveling crane with the limit switch.

4. Clamp body is floating structure; the level of floating distance: ±20mm, floating vertical distance:±10mm

5. Brake and hydraulic station is overall structure(please tell us if you want them to be separate)


4.Specifications/Technical parameters

Technical parameter of YJGQ hydraulic rail clip device    unit (mm)

Brake type

Clamping force(KN)

A

B

C

N-Φ D

E

F

G

H

J

L

YJGQ-16

160

820

870

630

6-Φ26

790

110

80

80

>310

650

YJGQ-20

200

820

870

630

6-Φ26

790

110

80

80

>310

650

YJGQ-25

250

930

890

720

8-Φ30

835

97

93

93

>380

650

YJGQ-31

315

930

890

720

8-Φ30

835

97

93

93

>380

650

YJGQ-40

400

1100

1100

830

8-Φ33

1050

125

100

100

>410

705

YJGQ-60

600

1250

1250

830

8-Φ40

1100

125

100

100

>410

705

Clip rail and rail hydraulic device Table:

Clamp model

YJGQ-16

YJGQ-20

YJGQ-25

YJGQ-31

YJGQ-40

YJGQ-60

Rail model

QU100, QU80, QU70, P50

QU80, QU100, QU120

QU120




Matched hydraulic station

YZ(J)-13-4

YZ(J)-10-6

YZ(J)-13-6

YZ(J)-14-9

YZ(J)-14-9

YZ(J)-15-10


5.FAQ

1. Are you a manufacturer, trading company or a third party?

We are a manufacturer, and we have builded up our company since 2004.

2. Where is your factory located?

Our factory address is : Weizhuang industrial Park Changyuan County Xinxiang City, Henan Province, China.

3. How can i get to your factory?

Our factory is near zhengzhou Airport, we can pick you up in the airport.

4. If i will need to stay in your place for few days, is that possible to book the hotel for me?

It’s always my pleasure, hotel booking service is available.

5. What is your minimum order quantity, can you send me samples?

Our minimum quantity is 1 set, as our product is machinery equipment, it’s difficult to send you samples, however,we can send you catalog, warmly welcome you to come visit our company.

6. Which level of quality are your products?

We have got  ISO9001, ISO14001, OHSAS18001, TX, EX, MA etc certificate so far.

7. What is the delivery time of your machine?

In general, the delivery time of our machine is about 7 days, customized machine will be delivered as the negotiation with our clients.

8. Can the machine be customized as our need, such as put on our logo?

Surely our machine can be customized as your need, Put on your logo is also available.

9. As the shipping period will take long time, how can you make sure the machine won’t be broken?

Our machine is film wrapped, to make sure the machine can be delivered to our customer smoothly, we will use the steel wire to fix the machine with the container.,

10. May i know which payment will be accepted by your company?

So far 100%T/T before shipment, and 30% deposit paid by T/T, balance paid by L/C are available.

11. About the after-sale service, how can you solve the problems occurred of your overseas customer in time?

The warranty of our machine is normally 12 months, during this period, we will arrange the international express immediately, to make sure the replace parts to be delivered as soon as possible.

12. After we placing an order, will you arrange the installation of the machine at present?

All the machines will be tested well before delivered, so almost of them can be used directly, also our machine are easy to be installed, if you customer needs our assistance, we will be pleased to arrange the installation, but all the cost will be be charged by you.

13. How can i get the after-service?

A: We will send you the spare parts by free if the problems caused by us.

If it is the men-made problems,we also send the spare parts,however it is charged. Any problem, you can call us directly.

14.How can i trust your company?

A:With 20-years-professional design, we can provide you suitable suggestion and lowest price

1. Assessed by third party, national patents and ISO for all equipment,  .

2. For our machine, we do very well on belt transport,port handling,hoisting, metallurgical, mining and building machinery..

15.Is your price competitive?

A:  Only good quality machine we supply. Surely we will give you best factory price based on

superior product and service.

6.Please feel free to send us your detailed requirements, you would be satisfied with our service.
