BYT1-125Z/10.C Explosion-Protected Electro-Hydraulic Thruster

BYT1-125Z/10.C Explosion-Protected Electro-Hydraulic Thruster

The BYT1-125Z/10.C is a heavy-duty, Explosion-Protected (Flameproof) Electro-Hydraulic Thruster. It is a compact drive unit that integrates a motor, centrifugal pump, and hydraulic cylinder into a single housing. It is specifically engineered for use in hazardous environments where flammable gases, vapors, or coal dust are present.

The model number breakdown is as follows:

BYT1: The series designation for Explosion-Protected Electro-Hydraulic Thrusters.

125: The Nominal Thrust Force of 125 kgf (approximately 1250 N).

Z: Indicates the standard Thrust Rod (Pushrod) configuration.

10: The Nominal Stroke (Lift) of 100 mm.

C: A manufacturer-specific variant code, typically indicating a structural modification, a specific mounting interface, or a customized feature.

💡 Key Features & Characteristics

Explosion-Proof & Hazardous Area Rated:

Certification: Features an Ex d I Mb certified flameproof enclosure, making it safe for use in underground coal mines and other explosive atmospheres (Zone 1 / Group IIA, IIB).

Safety: The motor and junction box are designed to contain any internal explosion and prevent it from igniting the surrounding atmosphere. Never open the cover while the unit is energized (严禁带电开盖).

Robust Performance:

Thrust & Stroke: Delivers a nominal force of 1250 N with a 100 mm stroke, making it suitable for driving medium-sized industrial brakes or valves.

Power Supply: Standard industrial 3-phase AC 380V to 660V / 50Hz. The motor must be wired exactly according to the nameplate specifications.

Operating Temperature: Designed to operate in ambient temperatures ranging from -20°C / -25°C to +40°C.

Installation & Maintenance:

Mounting: Can be installed vertically or at an incline not exceeding ±15°, with the connecting rod facing upwards. The unit must be able to swing freely during operation, and the pushrod must not bear any radial force.

Cable Entry: The diameter of the incoming cable must perfectly match the rubber sealing grommet. There must be no gap between the grommet, cable, and outlet to maintain the explosion-proof integrity.

Grounding: The unit is equipped with a dedicated grounding screw and must be properly grounded according to regulations.

Hydraulic Oil: The unit is shipped without oil. Before use, you must fill it with clean hydraulic oil (e.g., DB-25) up to the oil level plug, pulling the pushrod up and down a few times to purge air bubbles.

🏭 Typical Applications

The BYT1-125Z/10.C is specifically built for high-risk industrial environments:

Mining: Underground coal mining equipment, conveyors, and hoists.

Metallurgy & Steel: Heavy-duty cranes and braking systems in steel mills.

Ports & Harbors: Ship-to-shore cranes and bulk material handling equipment.

General Industry: Driving block brakes, disc brakes, industrial valves, gates, and various lever mechanisms requiring往复 (reciprocating) or摆动 (swinging) motion.

📋 General Technical Specifications

表格

Note: The BYT1 series is the explosion-proof counterpart to the standard YT1 series. The "125Z/10" indicates a medium-force, 100mm stroke unit. The suffix ".C" implies a specific structural variant, so always cross-reference the physical mounting dimensions with the manufacturer's drawing. Ensure the hydraulic oil level is regularly checked, and the oil is replaced every 6 months or if it becomes contaminated.
