MWZ160-80 Series Electromagnetic Drum Brake – DC Drive, Spring Fail-Safe

MWZ160-80 Series Electromagnetic Drum Brake

Compared with AC electromagnetic brakes, this DC brake delivers smoother action, lower startup impact and less noise. The braking torque is freely adjustable to adapt to different load requirements. Equipped with high wear-resistant friction linings, it maintains consistent braking performance under long-time frequent operation. The robust cast iron structure provides good rigidity and vibration resistance. All linkage parts are precisely processed, and friction linings can be replaced conveniently to reduce maintenance downtime.

It is widely adopted as emergency and parking safety brake for overhead cranes, gantry cranes, electric hoists and other medium-duty industrial lifting equipment.

MWZ160-80 Series Electromagnetic Drum Brake is a DC-driven normally closed safety brake designed for medium-duty lifting machinery. It operates on the principle of spring braking and DC electromagnetic release. When the DC electromagnet is energized, the brake opens to enable normal equipment running. In the event of power cut or circuit failure, built-in compression springs rapidly drive the brake shoes to clamp the brake drum, achieving reliable fail-safe braking and avoiding accidents such as load falling and equipment drifting.

Different from AC electromagnetic brakes, this DC electromagnetic drum brake features gentle actuation, small impact and low operating noise, which greatly reduces mechanical shock to transmission components during frequent start-stop cycles. The braking torque can be continuously adjusted to match various load demands and working conditions. Fitted with high-performance non-asbestos friction linings, the brake maintains a stable friction coefficient, outstanding wear resistance and consistent braking capacity under long-term cyclic operation.

The brake adopts an integral high-rigidity cast iron frame with excellent vibration resistance and structural durability. All connecting hinge points are precisely machined to ensure sensitive and stable movement. Standard mounting dimensions facilitate direct installation and replacement. The friction linings can be disassembled and replaced quickly without extensive disassembly of the whole unit, cutting maintenance time and lowering operational costs.

With stable performance and high safety reliability, MWZ160-80 Series electromagnetic drum brake serves as an ideal parking and emergency braking device. It is widely used for overhead cranes, gantry cranes, electric hoists, winches and other medium-duty industrial hoisting equipment.

Core Features

Normally closed spring fail-safe structure; automatic braking takes effect once power is lost

DC electromagnetic drive, smooth movement, low impact and low noise

Flexibly adjustable braking torque to adapt to medium-load operating scenarios

High wear-resistant friction linings, stable braking performance and long service life

Sturdy cast iron body with strong vibration resistance for frequent start-stop working environments

Standard installation size, easy on-site assembly and quick lining replacement

Suitable for overhead cranes, hoists, winches and medium-duty lifting machinery
