Hydraulic Emergency Brake
SB series hydraulic emergency brake is mainly used for emergency safety braking of low-speed shaft of main lifting mechanism (boom pitching mechanism) of large and medium-sized cranes, or working braking and emergency braking of driving mechanism of large and medium-sized winch hoist and...
Description
SB series hydraulic emergency brake is mainly used for emergency safety braking of low-speed shaft of main lifting mechanism (boom pitching mechanism) of large and medium-sized cranes, or working braking and emergency braking of driving mechanism of large and medium-sized winch hoist and inclined belt conveyor, as well as safety braking of driving mechanism of cable car and cable crane.
Features
SB series hydraulic emergency brake normally closed design, safe and reliable.
A special disc spring applies force to brake, and a hydraulic drive release device is required.
The action is sensitive and the closing time is short.
It can be equipped with gate opening limit switch and gasket wear limit switch, which can carry out interlocking protection and fault display.
The high-performance non-asbestos hard friction pad has a stable friction coefficient, does not damage the brake disc and is insensitive to water media and salt spray.
Reasonable sealing structure design and imported famous brand seals have good effect and long life.
Flexible installation location, easy to use, adjust and maintain.
Technical data of SB series hydraulic emergency brake
Type | Clamp force (KN) | Oil cylinder volume (ml) | Clearance (mm) | Friction coefficient | Mounted bolt/performance class/mounted torque | Weight without bracket (kg) | ||||||||||||||||||
SB50 | 50 | 11 | 30 | 1-2 | 8-M20, 10.9, 680 | 90 | ||||||||||||||||||
SB100 | 100 | 12 | 50 | 1-2 | 8-M24, 10.9, 1200 | 150 | ||||||||||||||||||
SB160 | 160 | 12 | 70 | 1-2 | 8-M30, 10.9, 2200 | 310 | ||||||||||||||||||
SB250 | 250 | 13 | 95 | 1-2 | 8-M36, 10.9, 3540 | 552 | ||||||||||||||||||
SB315 | 315 | 14 | 115 | 1-2 | 8-M36, 10.9, 3540 | 672 | ||||||||||||||||||
SB400 | 400 | 12 | 170 | 1-2 | 8-M48, 10.9, 7400 | 1100 | ||||||||||||||||||
Application:
Product:
About us:
Zhongyuan Brake is a professional supplier of industrial brakes. Our customized products are mainly used in the fields of cement, steel, docks, winches, belt conveyors, locomotives, gantry cranes, tower cranes, bridge cranes, jib cranes and bridge cranes.
Please feel free to send us your requirements, and we will confirm for you as soon as possible.
Hot Tags: hydraulic emergency brake, China, manufacturers, supplier, factory, customized
