Ed30/5 Power-Driven Hydraulic Pusher
1 · Why Choose Ed30/5 Thruster ① The "Heart" of Small Brakes Integrated motor + centrifugal oil pump + cylinder. One unit drives the whole brake - push-out on power, spring-return on power-off. ② Direct YT1-25/5 Replacement Same 300 N / 50 mm as the legacy YT1-25/5, but with...
Description
1 · Why Choose Ed30/5 Thruster
① The "Heart" of Small Brakes
Integrated motor + centrifugal oil pump + cylinder. One unit drives the whole brake - push-out on power, spring-return on power-off.
② Direct YT1-25/5 Replacement
Same 300 N / 50 mm as the legacy YT1-25/5, but with cast-aluminum body, IP65, F-class non-immersed motor, and 0–180° mounting.
③ Spare-Part King
~80% of orders are replacements. Swapping an Ed30/5 is ten times cheaper than replacing the entire brake.
④ Quiet & High-Cycle
Low noise, up to 2,000 cycles/hour, S1 / S3-60% duty. Built for valves, gates, clamps and small drum brakes.
2 · Product Overview
The Ed series (Ed = Electro-hydraulic drive) is a range of short-stroke, single-acting thrusters introduced from German EMG Eldro technology, fully compliant with DIN15430 and Chinese standard JB/T 10603-2006.
Naming rule - Ed30/5:
Ed = Electro-hydraulic thruster series
30 = Rated thrust 300 N (at rated voltage & frequency)
/5 = Rated stroke 50 mm
How it works
Power ON: motor spins the centrifugal pump → oil pressure pushes the piston & push-rod upward → brake released.
Power OFF: motor stops, return spring pulls the rod back → brake closes (fail-safe).
Where it fits
Mounts on the brake frame as the release actuator. The brake itself supplies the spring-closing force. Together they form a complete NC (normally-closed) electro-hydraulic brake.
3 · Technical Specifications
| Parameter | Ed30/5 Value | Remarks |
|---|---|---|
| Rated thrust | 300 N | at rated voltage / frequency |
| Rated stroke | 50 mm | single-acting, spring return |
| Motor power | ~200 W | F-class insulation, non-immersed |
| Rated voltage | AC 380V / 50Hz (standard) | 220V / 440V / 60Hz on request |
| Push-out time | ~0.5 s | typical at rated supply |
| Return time | ~0.4 s | spring-dependent |
| Duty | S1 / S3-60% | up to ~2,000 cyc/h |
| Protection | IP65 | fully sealed, outdoor-ready |
| Mounting | 0 – 180°任意角度 | any orientation |
| Weight | ~14 kg | cast aluminum housing |
| Standards | DIN15430 / JB/T 10603-2006 | EMG Eldro-compatible |
Note: "30" = 300 N and "/5" = 50 mm are nominal ratings. Actual thrust varies slightly with supply voltage and oil temperature. For critical applications confirm the value under your operating conditions.
