JZ-300 JZ Series Energy-saving Electromagnetic Drum Brake

Product Overview

JZ-300 electromagnetic drum brake adopts the classic spring-applied braking, electromagnetic release fail-safe working principle. It is equipped with a high-efficiency energy-saving electromagnetic coil as the driving core component.

When powered on, the electromagnet generates stable magnetic suction to drive the linkage mechanism, overcome spring preload and release the brake, allowing the equipment to operate normally. Once power is cut off or the electrical system fails, the internal high-strength compression spring instantly pushes the brake shoes to tightly clamp the brake drum, realizing automatic emergency braking and parking holding.

Different from conventional electromagnetic brakes, the JZ-300 adopts an optimized coil structure, which effectively reduces operating temperature rise and power loss during long-term continuous work. With robust integral frame structure, stable braking torque and excellent durability, it is an upgraded replacement for traditional TJ2 series brakes and widely recognized in industrial heavy-duty braking fields.

Core Features & Product Advantages

Energy-Saving & Low Heat Generation: Upgraded energy-saving electromagnetic coil design, greatly reduces continuous working power consumption and coil temperature rise, avoids coil burnout caused by long-hour operation, and extends the service life of the whole machine.

Strict Fail-Safe Protection: Normally closed power-off braking structure. Automatic emergency braking when power fails, cuts off or circuit malfunctions, effectively prevents equipment runaway, load falling and safety accidents, meeting global industrial safety specifications.

High-Frequency Stable Braking: Optimized mechanical linkage and electromagnetic driving structure, sensitive response, fast release and braking speed, smooth operation without jitter or impact, suitable for long-term high-cycle intermittent working conditions.

Adjustable Braking Torque: The spring preload can be finely adjusted on-site to change the braking torque, which flexibly meets the deceleration, parking and load-holding requirements of different load equipment.

Durable & Low Maintenance: Key hinge parts adopt self-lubricating bearings with flexible movement and wear resistance. The overall structure is sturdy with fewer vulnerable parts, greatly reducing daily maintenance frequency and operation cost.

Quick Replaceable Friction Lining: Equipped with high-performance non-asbestos wear-resistant lining. The lining replacement process is simple and efficient without disassembling the whole brake, saving maintenance time and labor cost.

Strong Environmental Adaptability: Reliable sealing and anti-rust treatment, stable operation in dusty, humid and ordinary industrial environments, low failure rate and strong environmental resistance.

Cost-Effective Upgraded Replacement: Better energy-saving performance and higher stability than traditional TJ2 series brakes, with moderate price and higher comprehensive cost performance.

Wide Application Scope

JZ-300 energy-saving electromagnetic drum brake is specially designed for medium and heavy-duty industrial mechanical equipment that requires frequent braking and long-term stable operation, widely used in:

• Overhead cranes, gantry cranes, electric hoists and industrial winches
• Belt conveyors and bulk material conveying machinery in mines, ports and factories
• Metallurgical, chemical, building materials and heavy industrial transmission equipment
• Port logistics handling machinery and construction engineering machinery
• Automatic production line transmission equipment requiring safe parking and emergency stop
• All medium-load industrial equipment needing fail-safe power-off braking and load holding

Detailed Technical Parameters
