Foot-operated Hydraulic Drum Brake
TYWZ2 series drum brakes are mainly used for smooth deceleration braking of medium and small cranes. It is a normally open brake, which provides a method for the operator to slow down and slow down smoothly.
Description
TYWZ2 series foot-operated hydraulic drum brake
Working conditions:
1. Ambient temperature: -20°C~+50°C;
2. Relative humidity: ≤90%;
3. Please confirm with us if you have special requirements.
Basic parameters:
Product model: TYWZ2-200, TYWZ2-300, TYWZ2-315, TYWZ2-400
Applicable wheel diameter: 200～400mm
Braking torque: 200～800Nm
Features
Normally open vertical installation
Stable braking and accurate positioning
No power required
Brake Type | Brake torque N.M | D | h | k | i | d | n | b | c | G | F | E | A | H | Weight Kg |
TYWZ2-200 | 0-200 | 200 | 170 | 175 | 60 | 17 | 10 | 90 | 135 | 195 | 100 | 300 | 320 | 440 | 42 |
TYWZ2-300 | 0-400 | 300 | 240 | 250 | 80 | 22 | 12 | 140 | 160 | 275 | 130 | 360 | 380 | 610 | 56 |
TYWZ2-315 | 0-400 | 315 | 240 | 250 | 80 | 22 | 12 | 125 | 186 | 275 | 130 | 375 | 390 | 610 | 60 |
TYWZ2-400 | 0-800 | 400 | 320 | 325 | 130 | 22 | 14 | 180 | 210 | 380 | 180 | 445 | 445 | 780 | 84 |
Hot Tags: foot-operated hydraulic drum brake, China, manufacturers, supplier, factory, customized
