Ed80/6 Electro Hydraulic Thruster With C Spring
ED series electric hydraulic driving device is a motor, centrifugal pump, oil cylinder as a whole, compact drive control device, has been widely used in various drum brake and disc brake driving device, also can be used for various industrial valves, gate, directional swing and rotation ( < 90degrees ) device ( mechanism ) and clamping device driving device.
Description
Ed80/6 Electro Hydraulic Thruster
Model: Ed80/6
Thurst: 800N
Rated Stroke: 60mm
Braking spring force: 750N (with C spring)
Power: 330W
Rated Currect: 1.42a
Certification: ISO9001, ISO14001, OHSAS18001, TX, EX, MA etc
Packing: export standard
Operating Condition" Ambient temperature: -20°C~+50°C ;
Relative humidity:≤90%;
Power：AC 3 phases 50（60）Hz
Voltages: 380~400V 50Hz 440~460V 60Hz
Operating duty: intermittent (S3-60%.1200times per hour)and continuous (S1).
Special requirements can be discussed in order.
