Electro Hydraulic Disc Brake For High Speed Shaft
YP11.YP21.YP31 series electro hydraulic disc brake for high speed shaft The brake is a high-performance, multi-functional advanced product. Due to its advanced functions such as automatic equalization of shoe clearance and automatic compensation of pad wear, it is very convenient to maintain...
Description
YP11.YP21.YP31 series electro hydraulic disc brake for high speed shaft
The brake is a high-performance, multi-functional advanced product.
Due to its advanced functions such as automatic equalization of shoe clearance and automatic compensation of pad wear, it is very convenient to maintain during use. By adding various limit switches, it can provide the required interlock protection signal to the host PLC.
Basic parameters:
Product model: YP11, YP21, YP31
Applicable disk diameter: 355～1100mm
Braking torque: 935～21200Nm
Zhongyuan brakes have the following advantages:
It is highly reliable and has a life span of no less than 10 years under correct maintenance.
The pins and fasteners are made of stainless steel or have special surface treatment.
The main swing intersections are all self-lubricating and do not require maintenance.
High-performance brake pads (non-asbestos).
Flexible installation location, easy adjustment and maintenance.
| Brake Type | Disc Dia(mm) | Disc thickness(mm) | Mb(Nm) | Clearance(mm) | Thruster model | Weight |
| YP11 | 250-500 | 20 | 200-610 | 0.8-1 | Ed200-50,Ed300-50 | 91-94 |
| YP21 | 355-630 | 30 | 935-2750 | 0.8-1 | Ed500-60,Ed800-60 | 105-106 |
| YP31 | 450-1100 | 30 | 2700-18150 | 0.8-1 | Ed1250-60-Ed3000-60 | 226-236 |
| YP32 | 560-1100 | 30 | 10800-21200 | 0.8-1 | Ed3000-80 | 236 |
| YP41 | 630-1250 | 30 | 15000-336000 | 0.8-1 | Ed4500-80 | 410 |
If you want more detailed information, please feel free to contact Zhongyuan Brake, we can also design various non standard brakes for users.
