The braking function of the gantry crane is very important. If the gantry crane has no brakes, it is equivalent to a car without brakes, and the consequences are very serious.
When the gantry crane is operating horizontal equipment, the inclination between the push rod and the vertical surface should be less than 5 degrees. The brake lining gap should be adjusted evenly from left to right and the gap bolts can be adjusted. When the brake is released, the brake pad should be parallel to the brake wheel. When locking the brake, tighten the brake wheel. The working surface of the brake wheel is clean and free of grease. The length of the brake tension spring can be adjusted by adjusting the working length of the tension spring screw to reach the required torque. The screw can use the distance between the brake pads to adjust the distance between the brake pads. When the brake pads are worn, the joystick can be adjusted to eliminate the wear. The working interval of the brake shoe should be as small as possible to ensure that the working stroke of the brake shoe is as small as possible. Therefore, it is necessary to adjust the propeller height. Before the gantry crane is commissioned, the push rod must be filled with conventional oil, and a suitable and clean oil must be selected to make the oil level reach the normal oil level.
