Air Caliper Disc Brake
QPD, CQPD Series Air Caliper Disc Brake Air caliper disc brakes are also called air brakes or air disc brakes and can be divided into disc brakes and shaft brakes. The brake can be divided into normally open (CQPD) and normally closed (QPD). Specifications/Technical parameters Technical data and...
Description
QPD, CQPD Series Air Caliper Disc Brake
Air caliper disc brakes are also called air brakes or air disc brakes and can be divided into disc brakes and shaft brakes. The brake can be divided into normally open (CQPD) and normally closed (QPD).
Specifications/Technical parameters
Technical data and dimensions of QPD air caliper disc brake
Type | B | C | D | E | H | L | D2 | Braking impulse (N) | Release Pressure min (Mpa) | Weight (Kg) |
QPD-25.4B | 220 | 190 | ≥610 | 25.4 | 417.5 | RC3/8 | D-250 | 14150 | 0.5 | 61 |
QPD-25.4A | 299 | 280 | ≥610 | 25.4 | 462.5 | RC1/2 | D-250 | 32000 | 0.5 | 70 |
QPD-40B | 220 | 190 | ≥610 | 40 | 417.5 | RC3/8 | D-250 | 14150 | 0.5 | 61 |
QPD-40A | 299 | 280 | ≥610 | 40 | 462.5 | RC1/2 | D-250 | 32000 | 0.5 | 70 |
Technical data and dimensions of CQPD air caliper disc brake
Type | B | C | D | E | H | L | D2 | Compression ratio | Cylinder volume (d m³) | Max pressure | Weight (Kg) |
CQDP-25.4B | 220 | 190 | ≥610 | 25.4 | 417.5 | RC3/8 | D-250 | 2.82 | 0.7 | 0.7 | 57 |
CQPD-25.4A | 299 | 280 | ≥610 | 25.4 | 462.5 | RC1/2 | D-250 | 2.82 | 3 | 0.7 | 63 |
CQPD-40B | 220 | 190 | ≥610 | 40 | 417.5 | RC3/8 | D-250 | 2.82 | 0.7 | 0.7 | 57 |
CQPD-40A | 299 | 280 | ≥610 | 40 | 462.5 | RC1/2 | D-250 | 2.82 | 3 | 0.7 | 63 |
Main feature:
1. Waterproof, dustproof, high temperature resistance, high durability and stable performance.
2. Adopt air pressure action, no electric spark, explosion-proof, safe and reliable.
3. The braking force can be adjusted arbitrarily, and the braking torque range is wide.
4. Good heat dissipation. The friction plate is friction-resistant and easy to replace.
Application:
Disc-type pneumatic brakes are widely used in parking brakes or deceleration brakes of small and medium-sized drive mechanisms, and tension brakes of winding mechanisms.
Standard size disc brakes are available or can be manufactured custom.
Zhongyuan Brake specializes in the design, production and supply of industrial brakes. If you have any needs, please feel free to contact us.
