DYTP1000-S/110 Electro-hydraulic Pusher





💡 Key Features & Characteristics

Fully Integrated Electro-Hydraulic Operation:

Self-Contained System: The device operates by using an electric motor to drive a bidirectional hydraulic pump. The pump outputs pressurized oil through an integrated valve block to the cylinder, achieving smooth and precise piston rod reciprocation (push and pull).

Fail-Safe Self-Locking: Equipped with a built-in hydraulic lock (check valve). If the power is suddenly cut off, the pusher will automatically lock in its current position and maintain its output force, preventing accidents and ensuring safety.

High-Performance Specifications (DYTP1000-S/110):

Rated Output Force: Delivers a powerful 10000 N of thrust and 7500 N of pulling force.

Rated Speed: Achieves a pushing speed of 110 mm/s and a pulling speed of 140 mm/s (when used horizontally).

Motor Power: Driven by a 1.5 kW electric motor (typically a Y90L-4 model).

Power Supply: Operates on a standard industrial 3-phase AC 380V / 50Hz power supply.

Robust & Maintenance-Friendly Design:

Overload Protection: Features a built-in relief valve. If the external load exceeds the rated force or the piston reaches its limit, the valve automatically溢流 (overflows) to protect the motor and internal components from damage.

Fully Enclosed Structure: The机电液一体化 (mechatronic) design is housed in a sealed steel cylinder. It does not leak oil, and in harsh environments, it effectively prevents dust and water ingress, preventing internal corrosion and extending service life.

Smooth & Precise Control: Utilizes full hydraulic transmission for highly stable operation. It can effectively buffer external impact forces and offers precise行程控制 (stroke control) with an accuracy of ≥≥ 0.5 mm.

Infinitely Adjustable: Both the output force and operating speed can be infinitely adjusted within their rated ranges to meet specific application requirements.

Flexible Installation:

Multi-Position Mounting: Can be installed horizontally, inclined upwards, or inclined downwards.

Note: If installed vertically (pushing up or down), the operating speed will be approximately half of the rated horizontal speed due to gravity.

🏭 Typical Applications

The DYTP1000-S/110 is a versatile power source used across various heavy industries:

Metallurgy & Mining: Used to control the opening and closing of valves, gates, and hoppers, as well as for clamping and shifting heavy materials.

Material Handling: Ideal for actuating conveyor belt diverters, trippers, and various clamping mechanisms on automated production lines.

General Industrial Automation: Can be networked with computers for centralized program control, making it perfect for remote, high-altitude, or hazardous areas requiring precise linear motion.

📋 General Technical Specifications

表格

Parameter	Description
Type	Electro-Hydraulic Pusher (Actuator)
Model Series	DYTP Series
Model Variant	DYTP1000-S/110
Rated Thrust / Pull Force	10000 N / 7500 N
Rated Push / Pull Speed	110 mm/s / 140 mm/s (Horizontal)
Motor Power	1.5 kW (Y90L-4)
Power Supply	3-phase AC 380V / 50Hz
Protection Rating	IP44
Stroke Range	Typically 50 - 1500 mm (Customizable)
Key Features	Overload protection, fail-safe self-locking, infinitely adjustable

Note: The DYTP1000-S/110 is a highly reliable industrial component. When selecting this model, be sure to specify the exact stroke length (the "S" in the model number) and the required installation angle. If operating in extreme temperatures or corrosive environments, please consult the manufacturer for specialized sealing and housing options. Regular inspection of the hydraulic oil and external seals will ensure decades of smooth, maintenance-free service.
