DYTZW1000-S/110 Electro-hydraulic Pusher

DYTZW1000-S/110 electro-hydraulic pusher

The DYTZW1000-S/110 is a heavy-duty, integrated electro-hydraulic actuator designed to convert rotary motor motion into linear reciprocating motion. It is typically used to drive industrial brakes, valves, or gates.

The model number breakdown is as follows:

DYTZ: The series designation for Integral Straight Electro-Hydraulic Thrusters.

W: A variant code, typically indicating Outdoor/Corrosion-Resistant protection (suitable for harsh environments).

1000: The Rated Thrust Force of 10,000 N (approx. 1,000 kgf or 1 ton).

S: Likely indicates a specific Mounting or Stroke Configuration (e.g., Standard or Specific attachment).

110: The Rated Speed of 110 mm/s.

💡 Key Features & Characteristics

High Thrust & Speed:

Thrust: Capable of generating a massive 10,000 N of force, making it suitable for large industrial brakes or heavy valve operations.

Speed: Operates at a linear speed of 110 mm/s, providing a balance between power and response time.

Robust "W" Series Protection:

Environment: The "W" designation implies enhanced protection against environmental factors. It is designed to operate in temperatures ranging from -20°C to +60°C.

Sealing: Features a fully enclosed,机电-hydraulic integrated structure that prevents dust ingress and water splashes, preventing internal rust.

Integrated Design:

Construction: The unit combines the motor, hydraulic pump, and cylinder into a single compact steel tube. It requires no external hydraulic lines, making installation simple.

Motor: Typically powered by a 1.5 kW motor (e.g., Y90L-4 type), running on 380V / 50Hz (3-Phase).

Safety & Control:

Overload Protection: Equipped with an internal overflow valve. If the load exceeds the rated force or the piston reaches the limit, the valve opens to prevent motor damage.

Self-Locking: Features a hydraulic self-locking mechanism. If power is cut, the piston remains in position (unless manually released), ensuring safety in braking applications.

Adjustability: The thrust and speed can often be adjusted via the hydraulic system or external controls (if equipped).

🏭 Typical Applications

The DYTZW1000-S/110 is used in heavy industrial environments requiring high force and reliability:

Brake Actuation: Driving large Electro-Hydraulic Drum Brakes (YWZ series) for cranes and hoists.

Port & Mining: Suitable for outdoor applications like ship-to-shore cranes, bucket-wheel excavators, and conveyors due to its "W" (weather-resistant) build.

Metallurgy: Operating heavy-duty valves, gates, and dampers in steel mills.

General Industry: Material handling, sorting systems, and clamping devices.

📋 General Technical Specifications

表格

Note: The DYTZ series is a "push-pull" device. The "1000" rating (10,000 N) is significantly higher than the "320" rating (320 N) of the YT1 series, making this a much more powerful unit suitable for heavy machinery. The "W" variant is essential for outdoor installations to prevent premature failure due to rust or moisture.
