YT1-25 ELECTRO AND HYDRAULIC THRUSTER

The company's products are widely used in domestic lifting transportation, port machinery, metallurgical machinery, railway machinery, hydraulic machinery, mining machinery and other industries.

The YT1 electro-hydraulic pusher is composed of two parts, the drive motor and the body (centrifugal pump). The body part is composed of a cover, a cylinder, a piston, an impeller and a rotor. When energized, the motor drives the impeller on the transmission shaft and the shaft to rotate.

Pressure is generated in the piston, under the influence of this pressure, the oil is sucked from the upper part of the piston to the lower part of the piston, forcing the piston and the push rod and beam fixed on it to rise rapidly. The load spring is mechanically compressed by the lever (the pusher or brake is loaded Spring) to produce mechanical movement. (If it matches with YWZ series hydraulic pusher, the brake will be released).

When the power is cut off, the impeller stops rotating, and the piston will quickly sink under the load spring force and its own gravity, forcing the oil to re- It flows into the upper part of the piston, which is still restored to its original position through the lever mechanism. (If it matches the YWZ series brake, the brake will be applied).
