YW-L Series Electro-Hydraulic Block Brake
YW-L Series Electro-Hydraulic Block Brake Standard: Brake connection size and braking torque parameters conform to JB/T6406-2006 standard and DIN15435 standard. Safe and reliable. Green and environmental protection, non-asbestos liner. The hinge point of the main pendulum adopts an automatic...
Description
YW-L Series Electro-Hydraulic Block Brake
Standard: Brake connection size and braking torque parameters conform to JB/T6406-2006 standard and DIN15435 standard.
Safe and reliable.
Green and environmental protection, non-asbestos liner.
The hinge point of the main pendulum adopts an automatic compensation mechanism for high efficiency, long life, and brake pad wear.
Other retreat devices can be installed.
Application
YW-L series electro-hydraulic block brakes are widely used in deceleration and parking (maintenance) braking of various mechanisms in various lifting and transportation, port loading and unloading, metallurgical equipment, mining machinery and construction machinery.
This series of brakes are mainly suitable for places where the installation space is small and where YW, YWZ9, YWZ4 and other forms cannot be installed.
Model Meaning
Order Example
YW-L .315/E80
YW-L315/E80-M. S2. K1
YW-L315/E80-M. S1-440V. 60Hz
Outline And Installation Dimension
Technical Parameters
Model | Braking torque(Nm) | Clearance(mm) | Weight(kg) | |
Brake model | Thruster Model | |||
YW-L200/E23 | Ed23/5 | 200 | 0.6 | 46 |
YW-L200/E30 | Ed30/5 | 300 | 52 | |
YW-L250/E23 | Ed23/5 | 260 | 0.8 | 53 |
YW-L250/E30 | Ed30/5 | 380 | 61 | |
YW-L250/E50 | Ed50/6 | 700 | 69 | |
YW-L315/E23 | Ed23/5 | 290 | 1.0 | 72 |
YW-L315/E30 | Ed30/5 | 410 | 78 | |
YW-L315/E50 | Ed50/6 | 720 | 81 | |
YW-L315/E80 | Ed80/6 | 1200 | 92 | |
YW-L400/E30 | Ed30/5 | 390 | 1.25 | 98 |
YW-L400/E50 | Ed50/6 | 750 | 102 | |
YW-L400/E80 | Ed80/6 | 1250 | 114 | |
YW-L400/E121 | Ed121/6 | 1900 | 132 | |
YW-L500/E50 | Ed50/6 | 900 | 1.25 | 154 |
YW-L500/E80 | Ed80/6 | 1650 | 159 | |
YW-L500/E121 | Ed121/7 | 2500 | 176 | |
YW-L500/E201 | Ed201/7 | 4100 | 181 | |
