Electro Hydraulic Thrustors

YT1, BYT1 series of electric hydraulic driving device is a set of motor, centrifugal pump, oil cylinder as a whole, compact drive control device, can be used as YWZ4( A ), YWZ9( A ) series of electric hydraulic drum brake driving device, also can be used for various industrial valves, gates, swing and running ( directionalvertical installation ) device ( mechanism ) and clamping device drive control.

Features:

• Our Electro-Hydraulic Thrustor is provided with Clevis-Lug mounting, allowing them to be mounted up to ten degrees either way from the vertical.

•

• All the Rubber surfaces are immersed in Oil, there by requiring very less maintenance.

•

• One outstanding feature of Crane Control Equipments make Thrustor is that any Mechanical Overloading cannot cause Overloading of the Electric Motor.

•

• If the Load is greater than what the Thrustor can lift, the Piston will remain at the bottom of the Cylinder and the impeller will rotate harmlessly in Oil.

•

• In the absence of Load the Piston stops at the end of the stroke and the Impeller rotates in the Oil as mentioned above.
