Storming Braking Wedge
YFX Series Storming Braking Wedge The braking device is an important part to ensure the safe and normal operation of the crane. When lifting, use a braking device to prevent the hanging object or boom from falling. Or reduce the speed of the running mechanism, and finally stop the movement....
Description
YFX Series Storming Braking Wedge
The braking device is an important part to ensure the safe and normal operation of the crane. When lifting, use a braking device to prevent the hanging object or boom from falling. Or reduce the speed of the running mechanism, and finally stop the movement.
Order mark
Order example
YFX-600/80-L
YFX-600/80-R
Note: If power supply is 380V 50Hz, it is unnecessary to specify in order, if not, please specify voltage and frequency.
Outline and installation dimension
Specifications
Brake Type | A | B | C | D | E | F | G | H | I | J | K | L | M | N | h1 | Weight (Kg) | Thruster type |
YFX-350-80 | 350 | 640 | 20 | 180 | 310 | 60 | 55 | 520 | 460 | 165 | 100 | 18 | 360 | 607 | 8 | 129 | Ed80/6C Ed80/6SC |
YFX-500/80 | 500 | 640 | 20 | 240 | 310 | 60 | 55 | 480 | 430 | 165 | 100 | 18 | 360 | 605 | 8 | 129 | |
YFX-550/80 | 550 | 640 | 20 | 240 | 310 | 60 | 55 | 480 | 430 | 165 | 100 | 18 | 360 | 605 | 8 | 129 | |
YFX-600/80 | 600 | 760 | 25 | 260 | 315 | 60 | 120 | 650 | 600 | 170 | 100 | 22 | 360 | 725 | 8 | 146 | |
YFX-630/80 | 630 | 760 | 25 | 260 | 315 | 60 | 120 | 650 | 600 | 170 | 100 | 22 | 360 | 725 | 8 | 146 | |
YFX-700/80 | 700 | 760 | 25 | 300 | 315 | 70 | 120 | 700 | 650 | 170 | 100 | 22 | 360 | 725 | 8 | 146 | |
YFX-710/60 | 710 | 760 | 25 | 300 | 315 | 70 | 120 | 700 | 650 | 170 | 100 | 22 | 360 | 725 | 8 | 149 | |
YFX-800/80 | 800 | 950 | 25 | 300 | 355 | 70 | 120 | 700 | 650 | 170 | 100 | 22 | 395 | 915 | 8 | 164 |
Main feature:
A release limit switch is provided for interlock protection.
The main swing hinge points are equipped with self-lubricating bearings, which have high transmission efficiency, sensitive and reliable movements, and long service life.
With manual release function, maintenance is convenient.
The thruster has a spring reset function to avoid the insensitive wedge of the thruster from being reset in time after power failure.
The wedge is treated by special process, with high friction coefficient and good anti-corrosion performance.
The hydraulic storming braking wedge is mainly used as the auxiliary windbreak brake for various kinds of rail cranes, such as gantry cranes, loading and unloading cranes, such as ports, wharves and railways.
Henan Zhongyuan Brake Co.,Ltd is a modern company dedicated to the research, production, sales and service of industrial brake systems.
If you want more detailed information, please feel free to contact Zhongyuan Brake, we can also design various non standard brakes for users.
