YLZ40 Hydraulic Wheel Side Brake | Crane Windproof Safety Brake

Product Overview

YLZ40 hydraulic wheel brake is a wheel-mounted safety braking device designed for outdoor harsh working conditions. Different from traditional rail wedge brakes, it directly clamps the crane travelling wheel rim to realize all-round windproof locking and static parking braking.

This brake adopts disc spring group to provide stable and lasting braking force. Under standby and power-off state, the disc spring pushes the friction pad to tightly clamp the wheel rim, achieving reliable self-locking and anti-slip effect. When the equipment needs to operate, the centralized hydraulic station provides stable hydraulic pressure to overcome spring preload, separate the friction pad from the wheel, and release the brake completely.

With integrated compact structure, synchronous braking response and strong environmental adaptability, YLZ40 brake can realize multi-brake synchronous linkage control. It is the preferred upgraded windproof safety solution for modern port and outdoor heavy rail cranes.

Core Features & Product Advantages

Fail-Safe Power-off Braking: Disc spring group provides continuous braking force. Automatically locks the wheel when power or hydraulic pressure fails, effectively preventing crane sliding and storm runaway accidents, meeting international outdoor equipment safety standards.

Direct Wheel-Rim Clamping Design: Acts directly on the travelling wheel rim, no damage to crane rail, uniform stress, better wind resistance effect than traditional rail wedge brakes.

Stable Disc Spring Braking Performance: High-strength disc spring group features fatigue resistance and long service life, maintaining constant braking force without attenuation after long-term frequent operation.

Centralized Hydraulic Synchronous Control: Matched with unified hydraulic station, realizing synchronous release and braking of multiple brakes, ensuring consistent action of whole crane travelling mechanism.

Built-in Limit Switch Feedback: Real-time signal feedback of brake open/closed state, convenient for electrical interlock control and remote monitoring, improving equipment automation safety level.

Heavy-Duty & Weather Resistant: Integral cast steel body with anti-corrosion and dustproof treatment, adapting to outdoor open-air, dusty, humid and strong wind harsh environments.

High Wear-Resistant Friction Pad: Adopts special high friction coefficient and wear-resistant material, stable friction performance, low noise and long service life.

Easy Installation & Low Maintenance: Compact integrated structure, convenient wheel-side mounting. Standardized replaceable friction pads, simple daily maintenance and low operating cost.

Wide Application Scope

YLZ40 series hydraulic wheel brakes are widely used for windproof anti-slip and static parking braking of various outdoor heavy rail-mounted machinery:

Port rail-mounted gantry cranes (RMG) and container gantry cranes

Outdoor large gantry cranes, bridge cranes and travelling hoisting equipment

Stacker-reclaimers, ship unloaders and bulk material handling machinery

Metallurgical heavy-duty transfer trolleys and mining outdoor rail equipment

Large construction gantry cranes and yard fixed rail lifting machinery

All outdoor wheel-rail equipment requiring standby windproof locking and safety parking braking

Detailed Technical Parameters

Working Principle

Hydraulic Release (Equipment Running State)

When the crane needs to travel, the external hydraulic station outputs stable hydraulic pressure. The hydraulic cylinder overcomes the pre-tightening force of the disc spring group, pushes the brake caliper to retract the friction pad, and separates it from the travelling wheel rim. The brake is fully released without any clamping resistance, and the rail crane can operate normally and travel freely.

Spring Locking (Standby & Storm State)

When the equipment stops running, the hydraulic pressure is unloaded. Once encountering power failure, hydraulic system failure or strong storm weather, the high-strength disc spring group instantly releases elastic force, pushing the friction pad to tightly clamp the crane wheel rim. Reliable static braking friction force is formed to lock the travelling wheel firmly, completely avoiding equipment drifting, sliding and runaway safety accidents caused by outdoor strong wind.
