Crane Motor Disc Brakes
DJPZ crane motor disc brakes are an important component of the electric drive system. It is matched with the motor to form a series of electromagnetic three-phase asynchronous motors. Crane motor disc brakes are mainly used in metallurgy, chemical industry, construction, mining machinery and...
Description
DJPZ crane motor disc brakes are an important component of the electric drive system. It is matched with the motor to form a series of electromagnetic three-phase asynchronous motors. Crane motor disc brakes are mainly used in metallurgy, chemical industry, construction, mining machinery and other industries to achieve fast parking and accurate positioning, and safely brake the mechanism.
The brake has the advantages of compact structure, convenient installation, low noise, high sensitivity and reliable braking.
Technical parameter of DJPZ crane motor disc brakes
Type | Matching motor frame number | Brake torque (Nm) | Rated power（20℃）W | Braking time（ms） | Max.working air gap（mm） | Max.relative speed（rpm） | Rated voltage DC（V） |
DJPZ-02 | 63 | 2 | 25 | 0.2 | 0.6 | 3000 | 99 |
DJPZ-04 | 71 | 4 | 30 | 0.2 | 0.8 | 3000 | 99 |
DJPZ-08 | 80 | 7.5 | 40 | 0.2 | 1 | 3000 | 99 |
DJPZ-15 | 90 | 15 | 50 | 0.2 | 1 | 3000 | 99 |
DJPZ-30 | 100 | 30 | 65 | 0.2 | 1 | 3000 | 99 |
DJPZ-40 | 112 | 40 | 70 | 0.25 | 1 | 3000 | 170 |
DJPZ-80 | 132 | 75 | 95 | 0.25 | 1.2 | 3000 | 170 |
DJPZ-150 | 160 | 150 | 110 | 0.35 | 1.2 | 3000 | 170 |
DJPZ-200 | 180 | 200 | 150 | 0.35 | 1.2 | 3000 | 170 |
DJPZ-300 | 200 | 300 | 200 | 0.45 | 1.5 | 3000 | 170 |
DJPZ-450 | 225 | 450 | 200 | 0.45 | 1.5 | 3000 | 170 |
DJPZ-600 | 250 | 600 | 210 | 0.5 | 1.5 | 3000 | 170 |
DJPZ-850 | 280 | 850 | 340 | 0.6 | 1.5 | 3000 | 170 |
DJPZ-2000 | 315 | 2000 | 400 | 0.7 | 2 | 3000 | 170 |
Conditions of Use:
The altitude does not exceed 2000 meters.
The surrounding medium does not have enough gas and dust to corrode the metal and destroy the insulation. The surrounding air humidity is less than 90%.
During installation, there should be no oil and dust in the friction disc, friction plate and brake.
Series brake coil insulation class: B class.
Power supply 380V, 50Hz, working mode is S1 or S3
Our services
1. Professional supplier
2. Good service, fast reply
3. Short delivery time
4. Reasonable price and high quality
5. Long warranty time and technical support
6. Best after-sale service
Packaging and Shipping
1) Neutral packaging
2) Carton packaging
3) Wooden packing
4) According to customer requirements
Zhongyuan Brake provides electro hydraulic thruster, drum brake, disc brake design, development, manufacturing, transportation, operation training and other services.
