Air Applied Caliper Brake
QPL, CQPL Series Air Applied Caliper Brake The pneumatic brake utilizes the adjustment of air pressure, and the torque can be adjusted in a wide range. Suitable for emergency braking and tension control. QPL, CQPL series air applied caliper brake is widely used for parking brake or deceleration...
Description
QPL, CQPL Series Air Applied Caliper Brake
The pneumatic brake utilizes the adjustment of air pressure, and the torque can be adjusted in a wide range. Suitable for emergency braking and tension control.
QPL, CQPL series air applied caliper brake is widely used for parking brake or deceleration brake of small and medium drive mechanism. Tension brake of winding mechanism, such as paper mill roll paper tight, newsprint tension control in news printing, steel plate (steel wire) roll unwinding tension and wire and cable pay-off, unwinding tension control, etc.
Specifications/Technical parameters
Technical data and dimensions of QPL air disc brakes
Type | Braking impulse (N) | Release Pressure min (Mpa) | Weight (Kg) |
QPL-12.7C | 3000 | 0.5 | 12 |
QPL-12.7B | 5500 | 0.5 | 13 |
QPL-12.7A | 10400 | 0.5 | 15.1 |
QPL-25.4C | 3000 | 0.5 | 12 |
QPL-25.4B | 5500 | 0.5 | 13 |
QPL-25.4A | 10400 | 0.5 | 15.1 |
Technical data and dimensions of CQPL air disc brakes
Type | Compression ratio | Cylinder volume (d m³) | Max pressure | Weight (Kg) |
CQPL-12.7d | 1.86 | 0.1 | 0.7 | 9.5 |
CQPL-12.7C | 1.86 | 0.2 | 0.7 | 10.3 |
CQPL-12.7-B | 1.86 | 0.4 | 0.7 | 11.5 |
CQPL-12.7A | 1.86 | 0.7 | 0.7 | 14.3 |
CQPL-25.4D | 1.86 | 0.1 | 0.7 | 9.5 |
CQPL-25.4C | 1.86 | 0.2 | 0.7 | 10.3 |
CQPL-25.4B | 1.86 | 0.4 | 0.7 | 11.5 |
CQPL-25.4A | 1.86 | 0.7 | 0.7 | 14.3 |
Our advantage
Quality assurance
We have carried out strict inspection on each part and product, and try our best to ensure that no quality problems appear in the hands of customers
Good service
Answer customer questions within 8 hours. A service engineer will be on call 24 hours a day.
Price advantage
Factory direct sales, no middleman price difference
Rich experience
Products are sold to more than 20 provinces, municipalities and autonomous regions across the country, and are exported to dozens of countries in the Americas, Europe, Africa, Southeast Asia, etc.
Please feel free to send us your detailed requirements, you would be satisfied with our service.
